产品参数：

General
Rated Power Output at Stereo Mode 100W + 100W (8 ohms, 20Hz-20kHz, THD 0.09%)
Reference Power Output Stereo Mode 85W + 85W (4 ohms, 20Hz-20kHz, THD 0.15%)
Reference Power Output 110W+110W(FR), 110W(CN), 110W+110W(SUR), 110W+110W(SB) (8 ohms 1kHz, THD 0.7%)
100W+100W(FR), 100W(CN), 100W+100W(SUR), 100W+100W(SB) (4 ohms 1kHz, THD 0.7%)
Power requirements 240 V, 50/60Hz
Power consumption 360W
Standby Power consumption 0.5W
Dimensions (wxhxd) mm 430 x 157.5 x 388
Weight 13kg
Input/Output
A/V In/Out 5/1 (including Front AV In)
Audio In/Out/TV CEC 4/1/Yes (Including TV In & PHONO In)
HDMI In/Out 4/1 (Active Intelligence)
Component Video In/Out 3/1 (Pass through)
Multi Channel In 7.1ch
DMPORT 1
Optical In/Out/TV CEC 4/1/Yes (Including TV In & Front Opt. In)
Coaxial In/Out 3/0
Monitor Out 1
Pre Out 7.1 ch (including: FH/SB: Switchable)
Zone 2 Audio (Speaker & Line)
Video (Composite & Component)
Zone 3 Audio (Line)
RS232C 1
12V Trigger 1
IR Repeater In/Out 1 / 2
IRIUS Yes
Ethernet 4 (Switching HUB)
Feature • Support for 3D (Three Dimension) Video Source Over HDMI
• Experience High Definition Theater System
• Experience the Newly Developed Sony Proprietary HD Sound Field – HD-D.C.S.
• Enjoy Blu-ray Sound Quality & Dolby ProLogic IIz
• Connecting Your Network Components and PC through Network AV Receiver
• Enjoy Movie and Music in Other Zones.
