产品规格
频率响应 51Hz-24kHz +/-3dB
low frequency extension 40Hz
high frequency extension 30kHz
承载功率 150W continuous / 600W peak
recommended amplifier power 50 - 350W
灵敏度 94dB @ 2.83V / 1m
标称阻抗 4 ohms
mid-frequency crossover 600Hz
高频分频 3400Hz
最大声音输出 115dB (2 speakers in-room)
高频驱动头 0.75" (1.9cm) titanium diaphragm compression driver mated to 90° x 60° Tractrix® Horn
mid-frequency drivers 4.5" (11.4cm) aluminum diaphragm compression driver mated to 90° x 60° Tractrix® Horn
低频驱动头 7" (17.8cm) high-output, aluminum / Rohacell® / Kevlar® hybrid cone woofer
机箱材料 Constrained layer MDF (medium density fiberboard)
机箱类型 Bass-reflex via rear-firing port
高度 19.9" (50.6cm)
宽度 9.2" (23.4cm)
深度 13.5" (34.3cm)
重量 30 lbs (13.6kg)
饰面 Zebra-grain Linia veneer in a natural, merlot or espresso stain
开始生产年份 2008
