产品规格
频率响应 56Hz-24kHz +/-3dB
low frequency extension 39Hz
high frequency extension 30kHz
承载功率 250W continuous / 1000W peak
recommended amplifier power 50 - 600W
灵敏度 96dB @ 2.83V / 1m
标称阻抗 4 ohms
mid-frequency crossover 550Hz
高频分频 3400Hz
最大声音输出 115dB (in-room)
高频驱动头 0.75" (1.9cm) titanium diaphragm compression driver mated to 90° x 60° Tractrix® Horn
mid-frequency drivers 4.5" (11.4cm) aluminum diaphragm compression driver mated to 90° x 60° Tractrix® Horn
低频驱动头 Dual 7" (17.8cm) high-output, aluminum / Rohacell® / Kevlar® hybrid cone woofers
机箱材料 Constrained layer MDF (medium density fiberboard)
机箱类型 Bass-reflex via dual rear-firing ports
高度 9.4" (23.9cm)
宽度 32.9" (83.6cm)
深度 17.5" (44.5cm)
重量 52 lbs (23.6kg)
饰面 Zebra-grain Linia veneer in a natural, merlot or espresso stain
开始生产年份 2008
