产品规格
频率响应 72Hz-24kHz +/-3dB
low frequency extension 54Hz
high frequency extension 30kHz
承载功率 150W continuous / 600W peak
recommended amplifier power 50 - 350W
灵敏度 96dB @ 2.83V / 1m
标称阻抗 4 ohms
高频分频 2000Hz
最大声音输出 117dB (2 speakers in-room)
高频驱动头 Dual 0.75" (1.9cm) titanium diaphragm compression drivers mated to 90° x 70° Tractrix® Horns in a WDST array
低频驱动头 Dual 7" (17.8cm) high-output, aluminum / Rohacell® / Kevlar® hybrid cone woofers
机箱材料 CTS composite
机箱类型 Bass-reflex via dual front-firing ports
高度 20.5" (52.1cm)
宽度 13.75" (34.9cm)
深度 7" (17.8cm)
重量 25 lbs (11.4kg)
饰面 Cabinet features a dark smoked nickel satin finish, end caps feature a zebra-grain Linia veneer available in a natural, merlot or espresso stain
开始生产年份 2008
