Technical specifications Pro-Ject Juke Box
Fitted cartridge Ortofon OM 5E
Built in amplifier 2 x 20W/30W (8 Ohm/4 Ohm)
Built in phono pre-amplifier MM
Nominal speeds 33 / 45 / 78 U/Min (78 optional)
Dust cover yes
RCA phono sockets 3 Line level inputs
Input at the front no
Record out no
Feet / damping material PVC / rubber
Tonearm Pro-Ject 8.6
Armtube / headshell made of aluminium / aluminium
Effective tonearm length 8,6“ (218,5mm)
Effective tonearm mass 9,5g
Overhang 18,5mm
Supplied counterweight for cartridge weight 3 - 5,5g
Optional counterweights for cartridge weight 1,5 - 3g, 6 - 9g
Downforce range 10 - 35mN
Speed variance ±0,9%
Wow and flutter ±0,15%
Signal to noise -55dB
Platter - weight / diameter 1,3kg/280mm
Power consumption 65W
Dimensions (dust cover open) 415 x 365 x 405mm
Dimensions (dust cover closed) 415 x 118 x 350mm
Weight 6,5kg
All dimensions W x H x D
