产品参数：

低音炮：
Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 218 × 150 × 178 mm Details
Weight： 4.8 kg
Principle： 1-way active, closed box
Woofers： 2 × 115 mm AS cone push-push / pull-pull configuration
Upper Cutoff Frequency： 60; 120; 180 Hz selectable
Frequency Range acc. to IEC： 268-5 36 ··· 200 Hz
Max Amplifier Power Subwoofer：2 × 40 W (sine) 55 W (pulse)
Satellites：2 × 40 W (sine) 55 W (pulse)
Inputs：
2 × line channels (RCA)
1 × Bluetooth® (A2DP, HFP, AVRCP)
Input Sensitivity Line： 2 × 200 mV
Input Impedance Line： 25 kΩ
Outputs： 2 × loudspeaker outputs for satellites with a lower cutoff frequency of 80 Hz
Mains Voltages： 90 ... 240 V~ / 50 ... 60 Hz external switching power supply
Power Consumption： max. 100 W (at full-load operation)

音箱：
Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 121 × 91 × 106 mm Details
Weight： 1.2 kg
Principle： 2-ways, closed box, integrated high-pass filter
Woofer： 1 × 80 mm AS cone, (mag. shielded)
Tweeter： 1 × 19 mm ringdome, (mag. shielded)
Recom. Amplifier Power at Nominal Impedance： 20-120 W / channel
Crossover Frequencies： 80 / 3,200 Hz
Sensitivity： 86 dB / 2.83 V / 1 m
Nominal Impedance： 4 Ω
suitable for amplifiers (from ... to)： 4 ... 8 Ω
Minimum Impedance： 3.3 Ω at 450 Hz
Frequency Range acc. to IEC： 268-5 80 ··· 21,000 Hz
Nominal / Peak Power Handling： 50 / 70 W
