产品参数：

Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 1,105 × 240 × 325 mm Details
Weight： 23 kg
Principle： 3½-ways, bass reflex
Woofers Bass Ports：
3 × 175 mm AS cone
1 × 60 mm with Bass Control Plug
1 × 100 mm (down firing)
Midrange： 1 × 140 mm AS cone, (mag. shielded)
Tweeter： 1 × JET III, (mag. shielded)
Recom. Amplifier Power at Nominal Impedance： 20-250 W / channel
Crossover Frequencies： 180 / 500 / 2,800 Hz
Sensitivity： 90 dB / 2.83 V / 1 m
Nominal Impedance： 6 Ω
suitable for amplifiers (from ... to)：4 ... 8 Ω
Minimum Impedance： 4.3 Ω at 110 Hz
Frequency Range acc. to IEC： 268-5 36 ··· 50,000 Hz
Nominal / Peak Power Handling： 140 / 200 W
