技术参数：

AUDIO INPUTS
Analogue Inputs 7 x DIN, 2 x RCA
Input Sensitivity 75mV
Input Impedance 47kΩ
Other Inputs Two inputs configurable for unity gain
AUDIO OUTPUTS
Analogue Outputs 1 x variable, 3 x fixed (DIN)
Line Outputs Fixed (level) 75mV, 600Ω
Line Outputs Variable (level) 775mV
Output Impedance <50Ω
Minimum Load Impedance 10kΩ
Power Outputs Naim phono amplifier
CONTROL
Infra Red RC5
Remote Input RCA on rear (RC5)
POWER
Supply Voltage +/-12V, 24V, 32V
Power Supply Options 552PS
PHYSICAL
Dimensions 87 x 432 x 314mm (H x W x D)
Weight 12.9kg
FINISH
Front Brushed and black anodised
Case Brushed and black anodised
