技术参数：

AUDIO INPUTS
Analogue Inputs 3.5mm front-panel socket, 1 RCA
Antenna Inputs Wi-Fi, F type, (plus PAL adapter)
Overload Margin 20dB
Input Sensitivity 270mV at 47KΩ
Digital Inputs 5 S/PDIF (2 optical, 2 coaxial, 1 digital/analogue 3.5mm jack)
USB Inputs 1 front-panel socket
Other Inputs Ethernet and iPod (digital via USB socket)
Tuning Range FM 87.5 - 108Mhz DAB Band III and L Band
AUDIO OUTPUTS
Signal To Noise Ratio (S/N ratio) 80dB
Power Outputs 45W per channel into 4Ω, 30W per channel in 8Ω
Digital Outputs (type) BNC 75Ω (plus RCA adapter)
Other Outputs Headphone
Audio Outputs Speaker output, preamp output (RCA)
CONTROL
IR Input Front panel only
RS232 Yes
Other Front panel logo touch-sensitive mute function
FORMATS
Audio Formats Supported Internet radio (Windows Media-formatted content, MP3 Streams, MMS), Playlists (M3U, PLS), MP3, AAC (up to 320kBit/s, CBR/VBR), Windows Media-formatted content-9 (up to 320kBit/s), FLAC and WAV (up to 24bit/96kHz via UPnp and USB only), OGG Vorbis
iRadio Service Provider vTuner 5* full service
POWER
Supply Voltage 100V, 115V, 230V; 50 or 60Hz
Power Consumption (maximum) 200VA
OTHER
Languages English, German, Italian, French, Spanish, Chinese, Dutch
Notes Windows Media is a trademark of Microsoft Corporation. UPnP is a trademark of the UPnP forum. iPod and Mac are trademarks of Apple Inc, registered in the U.S. and other countries.
PHYSICAL
Dimensions 87 x 207 x 314mm (H x W x D)
Weight 5.6Kg
FINISH
Front Black powder coated
Case Black powder coated
