产品参数：

低音炮：
Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 400 × 257 × 400 mm Details
Weight： 13 kg
Principle： 1-way active, bass reflex
Woofer： 1 × 200 mm AS cone
Upper Cutoff Frequency： 40 ··· 180 Hz, adjustable
Frequency Range acc. to IEC： 268-5 35 ··· 240 Hz
Max Amplifier Power： 80 W (sine) 100 W (pulse)
Inputs ：
1 × line channel (RCA)
3 × LS input channels
Input Sensitivity Line: 1 × 200 mV
LS:  3 × 2.5 V
auto switching threshold： 5 / 80 mV
shutoff delay about： 15 min
Input Impedance Line: 35 kΩ
LS:  220 Ω, floating
Outputs： 3 × LS passive high-pass filter with 220 µF
Mains Voltages：
 220 ... 240 V~ / 50 ... 60 Hz
110 ... 120 V~ / 50 ... 60 Hz
Power Consumption：
 max. 2 W (standby)
max. 200 W (at full-load operation)

音箱：
Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 121 × 91 × 106 mm Details
Weight： 1.2 kg
Principle： 2-ways, closed box, integrated high-pass filter
Woofer： 1 × 80 mm AS cone, (mag. shielded)
Tweeter： 1 × 19 mm ringdome, (mag. shielded)
Recom. Amplifier Power at Nominal Impedance： 20-120 W / channel
Crossover Frequencies： 80 / 3,200 Hz
Sensitivity： 86 dB / 2.83 V / 1 m
Nominal Impedance： 4 Ω
suitable for amplifiers (from ... to)：4 ... 8 Ω
Minimum Impedance： 3.3 Ω at 450 Hz
Frequency Range acc. to IEC： 268-5 80 ··· 21,000 Hz
Nominal / Peak Power Handling： 50 / 70 W
