产品参数：

低音炮：
Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 400 × 257 × 400 mm Details
Weight： 13 kg
Principle： 1-way active, bass reflex
Woofer： 1 × 200 mm AS cone
Upper Cutoff Frequency： 40 ··· 180 Hz, adjustable
Frequency Range acc. to IEC： 268-5 35 ··· 240 Hz
Max Amplifier Power： 80 W (sine) 100 W (pulse)
Inputs：
1 × line channel (RCA)
3 × LS input channels
Input Sensitivity Line：
1 × 200 mV
LS： 3 × 2.5 V
auto switching threshold： 5 / 80 mV
shutoff delay about： 15 min
Input Impedance Line： 35 kΩ
LS： 220 Ω, floating
Outputs： 3 × LS passive high-pass filter with 220 µF
Mains Voltages：
 220 ... 240 V~ / 50 ... 60 Hz
110 ... 120 V~ / 50 ... 60 Hz
Power Consumption：
 max. 2 W (standby)
max. 200 W (at full-load operation)

中置：
Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 88 × 290 × 102 mm
Weight： 2.1 kg
Principle： 2-ways, closed box, integrated high-pass filter
Woofers： 2 × 80 mm cone, (mag. shielded)
Tweeter： 1 × 25 mm dome, (mag. shielded)
Recom. Amplifier Power at Nominal Impedance： 20-150 W / channel
Crossover Frequencies： 85 / 3,800 Hz
Sensitivity： 87 dB / 2.83 V / 1 m
Nominal Impedance： 6 Ω
suitable for amplifiers (from ... to)：4 ... 8 Ω
Minimum Impedance： 4.8 Ω at 450 Hz
Frequency Range acc. to IEC： 268-5 85 ··· 21,000 Hz
Nominal / Peak Power Handling： 60 / 80 W

音箱：
Specifications
(Specifications and design features are subject to change.)

Dimensions H × W × D： 132 × 88 × 102 mm
Weight： 0.95 kg
Principle： 2-ways, closed box, integrated high-pass filter
Woofer： 1 × 80 mm cone, (mag. shielded)
Tweeter： 1 × 19 mm ringdome, (mag. shielded)
Recom. Amplifier Power at Nominal Impedance： 20-120 W / channel
Crossover Frequencies： 90 / 3,800 Hz
Sensitivity： 85 dB / 2.83 V / 1 m
Nominal Impedance： 6 Ω
suitable for amplifiers (from ... to)：4 ... 8 Ω
Minimum Impedance： 4.8 Ω at 450 Hz
Frequency Range acc. to IEC： 268-5 90 ··· 21,000 Hz
Nominal / Peak Power Handling： 45 / 65 W
