Technical specifications Pro-Ject Amp Box SE
Power output 2 x 80W/125W at 8ohms/4ohms (both channels driven)
Frequency response 10Hz - 50kHz (+0dB, -3)
Channel separation > 40dB at 20kHz
Noise floor > -90dB (A weighted)
THD < 0,1% at 90W
Gain 26dB
Pre in 1 pair RCA/Phono sockets
Input sensitivity 1,5V
Input impedance 100kohms
Speaker connectors 4mm Ø banana plugs, spades connectors or naked wire
Trigger 12V DC switching voltage
Trigger in and out 2-pole co-axial Ø 2,5mm jack
Outboard power supply 48V/2,5A DC, suitable for your country's mains supply
Power consumption 48V/2,5A DC
Dimensions W x H x D (D with sockets) 103 x 72 x 144 (163)mm
Weight 1.400g without power supply
