Azur 540R (Version 2) 6.1 AV Receiver
Ausgangsleistung: 100 Watts rms per channel,
8 ohms, two channels driven.
80 Watts rms per channel 8
ohms, all 6 channels driven

THD:

<0.006% @1kHz



Crosstalk:

<-60dB



Frequenzbereich:

20Hz – 20kHz +/- 1dB


Architecture:

CS42518 Multi-DAC
CS493263 DSP



Audio Inputs:

6 Line Level + Tuner
6.1 Direct Input


Audio Outputs: 6 Amplified Speaker Outputs,
6.1 Preamp output, 1 Tape record output

Video Inputs:

4 Composite, 3 S-Video,
2 Component Video


Video Outputs:

1 Composite, 1 S-Video,
1 Component Video


Digital Inputs:

2 Co-Axial, 3 Optical


Digital Outputs:

1 Co-Axial, 1 Optical


Standby Power Consumption:

<2w


Max. Leistungsaufnahme:

850w


Dimensions (W x D x H):

430 x 310 x 100mm
16.9 x 12.2 x 3.9"


Gewicht: 9.5kg/20.9lbs
